LEGION SLIM 5 16ARP9
PART NUMBER : 83EX001VLM
PERFORMANCE
PROCESSOR
AMD RYZEN 7 7435HS (8C / 16T, 3.1 / 4.5GHZ, 4MB L2 / 16MB L3)
AI PC CATEGORY
AI-POWERED GAMING PC
GRAPHICS
NVIDIA® GEFORCE RTX 4060 8GB GDDR6, BOOST CLOCK 2370MHZ, TGP 125W, 233 AI TOPS
CHIPSET
AMD SOC PLATFORM
MEMORY
1X 16GB SO-DIMM DDR5-4800
MEMORY SLOTS
TWO DDR5 SO-DIMM SLOTS, DUAL-CHANNEL CAPABLE
MAX MEMORY
UP TO 64GB DDR5-4800
STORAGE
512GB SSD M.2 2242 PCIE® 4.0X4 NVME®
STORAGE SUPPORT
UP TO TWO DRIVES, 2X M.2 SSD
M.2 2242 SSD UP TO 1TB
M.2 2280 SSD UP TO 1TB
STORAGE SLOT
TWO M.2 2280 PCIE® 4.0 X4 SLOTS
CARD READER
SD CARD READER
OPTICAL
NONE
AUDIO CHIP
HIGH DEFINITION (HD) AUDIO, REALTEK® ALC3287 CODEC
SPEAKERS
STEREO SPEAKERS, 2W X2, OPTIMIZED WITH NAHIMIC AUDIO
CAMERA
FHD 1080P WITH E-SHUTTER
MICROPHONE
2X, ARRAY
BATTERY
INTEGRATED 80WH
POWER ADAPTER
230W SLIM TIP (3-PIN)
SPECIAL FEATURES
AI CHIP: LA1
DESIGN
DISPLAY
16 WQXGA (2560X1600) IPS 350NITS ANTI-GLARE, 100% SRGB, 165HZ, DOLBY VISION®, G-SYNC®, FREE-SYNC PREMIUM, LOW BLUE LIGHT
TOUCHSCREEN
NONE
COLOR CALIBRATION
FACTORY COLOR CALIBRATION
KEYBOARD
4-ZONE RGB BACKLIT, SPANISH (LA)
TOUCHPAD
BUTTONLESS MYLAR® SURFACE MULTI-TOUCH TOUCHPAD, 75 X 120 MM (2.95 X 4.72 INCHES)
CASE COLOR
LUNA GREY
SURFACE TREATMENT
ALUMINIUM STAMPING (ANODIZED WITH SANDBLASTING)
CASE MATERIAL
ALUMINIUM (TOP), PC-ABS (BOTTOM)
DIMENSIONS (WXDXH)
359.7 X 260.5 X 19.9-21.9MM (14.16 X 10.26 X 0.78-0.86 INCHES)
WEIGHT
AROUND 2.3 KG (5.07 LBS)
SOFTWARE
OPERATING SYSTEM
WINDOWS® 11 HOME SINGLE LANGUAGE, SPANISH
BUNDLED SOFTWARE
OFFICE TRIAL
CONNECTIVITY
ETHERNET
100/1000M (RJ-45)
WLAN + BLUETOOTH
WI-FI® 6E, 802.11AX 2X2 + BT5.3
STANDARD PORTS
1X USB-C® (USB 10GBPS / USB 3.2 GEN 2), WITH LENOVO® PD 140W AND DISPLAYPORT 1.4
1X USB-A 10GBPS (USB 3.2 GEN 2)
1X USB-A 10GBPS (USB 3.2 GEN 2), ALWAYS ON
1X HDMI® 2.1, UP TO 8K/60HZ
1X HEADPHONE / MICROPHONE COMBO JACK (3.5MM)
1X ETHERNET (RJ-45)
1X CARD READER
1X POWER CONNECTOR
OPTIONAL PORTS (CONFIGURED)
1X USB-C® (USB 10GBPS / USB 3.2 GEN 2)
SECURITY AND PRIVACY
SECURITY CHIP
FIRMWARE TPM 2.0 ENABLED
FINGERPRINT READER
NONE
OTHER SECURITY
E-SHUTTER
SERVICE
BASE WARRANTY
1-YEAR, COURIER OR CARRY-IN
INCLUDED UPGRADE
NONE
ACCESSORIES
BUNDLED ACCESSORIES
NONE
CERTIFICATIONS
GREEN CERTIFICATIONS
ERP LOT 6
ERP LOT 26
ROHS COMPLIANT
OTHER CERTIFICATIONS
TÜV RHEINLAND® LOW BLUE LIGHT (HARDWARE SOLUTION)
